| Scheme |
4 ways, 5 loudspeaker bass-reflex scheme, and a floor type |
| Unit |
For low-pass: 2231Hx2
For inside low-pass: 2202H
For mid-high ranges: Horn type (2440+2311)
For high regions: Horn type (2405) |
| Play frequency band |
30Hz-20kHz±3dB |
| Cross over frequency |
250Hz, 1.1kHz, 9kHz |
| Directivity |
60 degrees x 30 degrees (12kHz) |
| Impedance |
4ohm (250Hz or less), 8ohm (250Hz or more) |
| Output sound pressure level |
95.5dB/W/m |
| Allowable input |
200W (250Hz or less), 100W (250Hz or more) |
| Enclosure dimension |
Woofer: 269L
Mid Woofer: 45.3L |
| Dimensions |
Width 1210x height 889x depth of 508mm |
| Weight |
118kg |
|
